Atago Malaysia RX-5000i Automatic Digital Refractometer | Muser Apac

Atago RX-5000i Automatic Digital Refractometer

  • Refractive Index range 1.32420 to 1.58000 nD
  • Brix range 0.00 to 100.00%
  • With Peltier temperture control from 5.00 to 75.00°C.

Atago Malaysia RX-5000i Automatic Digital Refractometer



  • The most accurate refractometer in the world is now even more stylish, smart, and functional.
  • Featuring intuitive touch screen technology, the new RX-i series makes navigation and selection a breeze. The RX-5000i measures with the same accuracy level as the RX-5000α ±0.03% Brix and ±0.00004 nD.
  • The RX-i series come with newly added functions, such as USB flash drive and self-diagnosis capability.
  • FDA 21 CFR Part 11 Software Included in Standard Delivery.

Atago RX-5000i | Feature Highlights

World’s Highest Standard of Accuracy
The RX series are the most accurate of ATAGO refractometers programmed with a trusted and advanced algorithm.

Ergonomically Designed Layout
The RX series was designed with ease of use in mind. The sample stage is placed on the right-side, while the buttons for operation and the LCD are placed on the left-side. This results in a distance of only 17 cm. Extensive research was performed in the design phase to ensure an ergonomic interface that made operation easy while maximizing efficiency.

Password Security
The password feature allows only authorized personnel to perform certain operations. Assign a system level and password to limit each operator’s activities.

Reliability
The new and advanced algorithm allows for more stable readings every time.

Speedy Measurement Results
Once the sample temperature has stabilized, measurement takes only a few seconds. Results are displayed instantly with excellent repeatability.

Programmable User Scale
Enter 3 to 5 data points of a scale, other than Brix, to directly display the concentration of specific solutions, such as DMF, and more. Save time and increase efficiency by eliminating the need to refer to manual conversion tables.

Rugged Metal Body
The sturdy, yet elegant die-cast metal body protects the optical system. A special coating on the surface adds extra durability against chemicals.

Wide Ambient Temperature Range
The ambient temperature range of 5 to 40°C allows measurements in a wide range of temperature conditions.

See all Atago products

Visit Atago website

Return Home



Specifications
ModelRX-5000i
Cat.No.3276
RangeRefractive index (nD) : 1.32420 to 1.58000 Brix : 0.00 to 100.00%
ResolutionRefractive index (nD) : 0.00001 Brix : 0.01% Temperature: 0.01°C
AccuracyRefractive index (nD) : ±0.00004 Brix : ±0.03%
Temperature control range5.00 to 75.00°C
Dimensions & Weight37×26×14cm, 6.6kg
Output terminals• Printer (for ATAGO digital printers) • Computer -USB
Warranty2 years standard (3 years with product registration) excluding touchscreen
Options
  • Digital Printer DP-63 (Thermal printer) : Cat.No.3118
  • Digital printer DP-AD (Dot matrix printer) : Cat.No.3123
  • MAGIC™ (metal) : RE-56180
  • MAGIC™ (resin) : RE-56185
  • Funnel-type Flow Cell : RE-56172
  • 10% High Accuracy Sucrose (±0.01%) : RE-111001
  • 20% High Accuracy Sucrose (±0.01%) : RE-112001
  • 30% High Accuracy Sucrose (±0.01%) : RE-113001
  • 40% High Accuracy Sucrose (±0.02%) : RE-114002
  • 50% High Accuracy Sucrose (±0.02%) : RE-115002
Parts
  • Printer paper (regular) for Thermal printer : RE-8412
  • Printer paper (long-term storage) for Thermal printer : RE-8414
  • Printer paper for Dot matrix printer : RE-89403
  • Ribbon cassette : RE-89402
  • Fan Filter Replacement : RE-58001
